Freedom, without limits! This commercial-rated electric utility vehicle is the ultimate workhorse. A powerful and reliable motor delivering up to 5kW means even loads of up to 500 kg are able to be moved effortlessly. It highspeed gear box also allows this utility to travel at speeds of 30km/h allowing tasks to be completed faster.
POWER TRAIN | |||||
|---|---|---|---|---|---|
Motor | |||||
5.0 kw AC Electric | |||||
Drive Axel | |||||
– | |||||
Transmission | |||||
– | |||||
Controller | |||||
48m-350a Controller | |||||
ENERGY |
|---|
Voltage |
48v |
Battery |
150 amp Specially Developed High Performance Lithium Battery To Carry Heavy Loads. |
Charger |
On-Board Charger (Fully Automatic) |
CHASSIS |
|---|
Body |
– |
Suspension |
Front Independent Suspension with Double Wishbone and coil over Shock Absorbers all round |
Brakes |
4 Wheel Hydraulic Disc Brakes |
Wheels |
10’’ Aluminum Rim with 205/65-10 Tires |
Steering |
Single Stage Rack & Pinion Steering System, Automatic Rocker Compensating Function |
Seats |
– |
EQUIPMENT | |||||
|---|---|---|---|---|---|
Lights | |||||
Amble Round LED System & warning lights | |||||
Indicators | |||||
Directional Indicator | |||||
Accessories | |||||
– | |||||
Safety | |||||
– | |||||
Specifications and standard equipment are subject to change without notice.
Motor | 5.0 kw AC Electric |
|---|
Drive Axle | – |
|---|
Transmission | – |
|---|
Controller | 48m-350a Controller |
|---|
Voltage | 48v |
|---|
Battery | 150 amp Specially Developed High Performance Lithium Battery To Carry Heavy Loads. |
|---|
Charger | On-Board Charger (Fully Automatic) |
|---|
Body |
|---|
PP Plastic with Automotive Finish, Moulded Plastic Roof, Hot Dipped Galvanised Steel Chassis |
Suspension | Front Independent Suspension with Double Wishbone and coil over Shock Absorbers all round |
|---|
Brakes | 4 Wheel Hydraulic Disc Brakes |
|---|
Wheels | 10’’ Aluminum Rim with 205/65-10 Tires |
|---|
Steering | Single Stage Rack & Pinion Steering System, Automatic Rocker Compensating Function |
|---|
Seats | – |
|---|
Lights | Amble Round LED System & warning lights |
|---|
Indicators | Directional Indicator |
|---|
Accessories | – |
|---|
Safety | – |
|---|
Specifications and standard equipment are subject to change without notice.
